Track Profile with Tooth Rack
Track Profile with Tooth Rack
Couldn't load pickup availability
Track with toothed rack for higher precision. Compatible with Track Runner with Cogwheel.
Mount your stage objects to the Track Runner and make your objects move along the track.
You can make linear as well as curved horizontal (min. 1,9 m radius) moving effects for your stage design.
| Length: | 1-6 m (3.28-19.69 ft) |
| Curved track: | Yes, min. 2 m (6.56 ft) radius |
Description
The Tooth Rack Track Profile is designed for the Track Runner with Cogwheel to carry any stage items along the track.
You can choose any length of track pieces between 1-6 m that fit the installation you are designing. You can connect the tracks together to increase the length and reach any track length you want.
It is a very flexible solution and can be fitted to meet any criteria of the environment where the Track System is set up.
If you want to move electrical equipment this is also possible. You can use the Cable Runners and make your electrical equipment like lamps move along the track.
Great to create further movements for your lighting design and increases your possibilities to work with the track profile in many different areas.
Tooth Rack Track Profile – Easy and precise moving effects
The Tooth Rack Track Profile comes with (as the name says) with tooth rack and thus compatible with our Track Runner with Cogwheel. The advantage of this is that it is very precise, and you can control movement and positions down to the millimeter.
We also have other track types to offer:
Have questions? We are ready to answer your questions and find the best solution for your needs. Contact us here.
Track Suspension intervals
| Point Load | Point Load | Point Load | Uniformly Distributed | Uniformly Distributed | Uniformly Distributed |
| 1m centres | 2m centres | 3m centres | 1m centres | 2m centres | 3m centres |
| 535kg | 265kg | 170kg | 1070kg | 530kg | 340kg |
The content of the Track Profile with Tooth Rack package
1 x Track Profile with Tooth Rack (x meter)
1 x Track Alignment Tool
Spare parts
At Wahlberg, we prioritize customer satisfaction. We understand the frustration of having a product that isn't working as it should and don't believe in discarding a perfectly good product just because one part isn't functioning properly. That’s why we offer spare parts for all our products. So, whether you choose to send in your Wahlberg product for professional servicing or prefer DIY repairs, we're here to help. Just download our Exploded View drawings for guidance, and you'll have your product fixed in no time!
Contact us at sales@wahlberg.dk if you can’t find the needed spare part on our website.
Specifications
| Item number | .342 |
|---|---|
| Length | 1-6 m (3.28-19.69 ft) |
| Curved track | Yes, min. 2 m (6.56 ft) radius |
| Mounting clamp | Minimum 2 x Slim eye coupler 42-52 mm (2 in) |
| Track safety factor | >5 |
| Weight | 5 kg/m (11.1 lb/m) |
| Dimensions | 1000-6000 x 51 x 100 mm (39.4-236.2 x 2 x 3.9 in) |
